ภาษาไทย
หมวดหมู่สินค้า: TOA
รหัส : PS15TOA1613
สินค้ารับประกัน 1 ปี
ราคายังไม่รวมภาษีมูลค่าเพิ่ม 7% ค่าแรงติดตั้ง และค่าจัดส่ง
จาก 91,000.00 บาท
ลดทันที 5%
ราคา 86,450.00 บาท
04 กุมภาพันธ์ 2569
ผู้ชม 4 ผู้ชม
CX-PA1240 1CE Power Amplifier 240W 10SS (240V)
- 240 W rated output
- 2 balanced audio inputs with phantom power on input 1
- 10 balanced speaker outputs, selectable 100 V / 70 V output voltage
- Signal processing with Gain, EQ, Comp, AGC, Trim, Gate(VOX), ANC
- Dual RJ45 connectors supporting key network protocols and multicast/unicast
- 10 direct keys and multiple LED indicators
- 10 control inputs and outputs with high capacity relay contacts
- Emergency cutoff input
Specifications
| Model | CX-PA2240 1CE |
| Power Source | 240 V AC 50/60 Hz |
| Rated Output | 240 W |
| Power Consumption | 330 W (rated output), 72 W (based on EN62368) |
| Audio Input | 1 channel, -60 dB (*1)/-40 dB (*1)/-20 dB (*1)/0 dB (*1) selectable, 10 kΩ, electronically balanced, phantom power supply available, removable terminal block (3 pins) 1 channel, -60 dB (*1)/0 dB (*1) selectable, 10 kΩ, electronically balanced, removable terminal block (3 pins) |
| Recording Output | 1 channel, 0 dB (*1), 10 kΩ, electronically balanced, removable terminal block (3 pins) |
| Audio Bandwidth | 200 Hz - 16 kHz |
| Signal to Noise Ratio | 60 dB or more |
| Distortion | 1 % or less at 1 kHz, rated power (20 kHz LPF (AUX-0025)) |
| Speaker Output | 10 channels, removable terminal block (10 pins x 2) |
| Output Voltage | 100 V/70 V switchable |
| Volume Control | Audio input volume control x 2, Recording output volume control x 1, Speaker output volume control x 1 |
| Signal Processing | Input channel: Gain, EQ x 2, Comp, AGC, Trim, Gate ( for VOX function) Output channel: Gain, EQ x 7, ANC |
| Network | Network I /F: 100BASE-TX Network protocol: TCP/IP, UDP, ARP, ICMP, HTTP, RTP, RTSP, IGMP, NTP, FTP, RSTP Audio packet transmission method: Unicast, Multicast Number of broadcasting destinations: Unicast (max. 1), Multicast (max. 2999) Connector: RJ45 connector x 2 Network cable: UTP (Cat5 or greater) |
| Audio Transmission | Sampling frequency: 48 kHz, 16 kHz (controllable on the software) Audio codec: PCM, G.722 Quantization bit depth: 16-bit Voice packet loss recovery: Silence insertion |
| Operation | Direct key x 10, Reset key x 1, CPU OFF switch x 1, Output voltage selection switch x 1, Input setting switch (input level setting (MIC/LINE selectable), phantom power setting) x 1 |
| Indicators | LED indicators: LAN (green) x 2, POWER (green) x 1, RUN (green) x 1, STATUS (yellow, red, green) x 1, INPUT (green, red) x 2, REC OUT (green, red) x 1, OUTPUT (green, red) x 1, CPU OFF (red) x 1 Direct keys: SELECT (green) x 10, STATUS (yellow, red, green) x 10 |
| Control Input | 10 channels, no-voltage make contact input, open voltage: 24 V DC, short-circuit current: 5 mA or less, removable terminal block (12 pins x 2) |
| Control Output | 10 channels, relay contact output, maximum contact capacity : 125 V AC/24 V DC, 4.0 A, removable terminal block (15 pins x 2) |
| Emergency Cutoff 24 V Input | 1 channel, photo coupler input, input current: 5 mA or less, removable terminal block (2 pins) |
| Installation Method | Desktop, rack, or wall mounting (Rack or wall mounting needs optional brackets.) |
| Operating Temperature | 0°c to +40 °c |
| Operating Humidity | 90 %RH (no condensation) |
| Finish | Panel, Case: Pre-coated steel plate, black, 30% gloss Volume control section cover: ABS resin, gray smoke |
| Dimensions | 420 (W) x 88.7 (H) x 326 (D) mm |
| Weight | 5.6 kg |
| Accessory | Power cord ( 2 m ( 6.56 ft)) ··-1, Removable terminal plug ( 2 pins) ---1, Removable terminal plug ( 3 pins) ·--3, Removable terminal plug ( 12 pins) ·--2, Removable terminal plug (10 pins) --·2, Removable terminal plug (15 pins) ---2, Plastic foot ·--4, Screw for fitting plastic foot --·4 |
| Option | Wall mounting bracket: YC-850 Rack mounting bracket: MB-25B |
